Sonic System acoustic modular panel-VR Datasheet

The Sonic System acoustic roof panel VR combines airborne noise reduction, noise absorption and thermal performance in a self-supporting roof panel for industrial and infrastructure applications.

Available in thicknesses from 50mm to 200mm, the Sonic System acoustic roof panel VR uses a solid profiled external steel sheet, perforated internal steel sheet and Rockwool core. It is designed for roofing applications where acoustic, structural and thermal performance need to be considered together.

The datasheet provides acoustic, structural and thermal performance information and detailed product specifications.

Product information

• Rw 33 at 50mm
• αw up to 1.0 at 50mm
• Panel thicknesses from 50mm to 200mm
• 1000 mm effective panel width
• Lengths up to 11,900mm
• 100 kg/m³ Rockwool core
• Thermal transmittance from 0.76 W/m²K at 50 mm to 0.20 W/m²K at 200 mm
• Structural performance assessed to EN 14509

Download the Sonic System acoustic roof panel VR datasheet for detailed product specifications and acoustic, structural and thermal performance information.
